NFlightMic NOMAD Aviation Microphone XLR5 Connector

NFlightMic
4404
    Delivery time:3-5 Days
Add to cart
  • Description

How it works:  The NFlightMic Nomad is an aviation microphone that can be attached to any headset using the included 3M Dual Lock.

The NFlightMic has a 2.5mm audio output that can be plugged into the headset's auxiliary audio input.

The NFlightMic Nomad accepts 3.5mm audio inputs, allowing you to listen to music while you fly.  It also has a mono/stereo selector switch, making it compatible with both mono and stereo aircraft intercoms.

The NFlightMic Nomad plugs into standard PJ or twin-plug jacks on any fixed-wing aircraft.

Click here to view the Nomad instruction manual in PDDF format

Try it for 30 days.  If you are not completely happy, we will refund your money.

Unconditional Lifetime Warranty:  If you send us a broken NFlightMic, we will replace it up to two times, even if the damage is from abuse.

Compatible with:  Bose QC25, Bose QC35, Bose QC35ii or any other headset with a 2.5mm auxiliary audio input.  Please note: The Bluetooth capability of the Bose QC35 is disabled when the mic is plugged in.

Can also be easily converted to be compatible with headsets with 3.5mm auxiliary audio inputs with the use of a 2.5mm-to-3.5mm adapter

Popular headsets with a 2.5mm-to-3.5mm adapter:  Sony 1000

TECHNICAL SPECIFICATIONS

General:

Connections:  Standard twin-plug PJ-style 3/16-inch and 1/4-inch aviation connectors

Supports both mono and stereo aircraft intercoms

Audio output:  2.5mm, 3-pole male connector

Auxiliary Audio Input:  3.5mm

Cable length:  2 meters or 39 inches

Audio output cable length:  10 centimeters or 4 inches

Flexible boom microphone length:  20 centimeters or 8 inches

Output volume:  adjustable

Attachment to headset:  3M Dual Lock circles (3M adhesive is removable without a trace.)

Included accessories:  shirt clip for strain relief, 3.5mm auxiliary audio cable, two extra 3M Dual Lock pads

Microphone:

Noise-canceling electret

Frequency response: 200 Hz - 6000 Hz

Maximum SPL: 114 dB

Terminating impedance: 220-2200 ohms

Operating voltage: 8V-16V DC
