NflightMic Standard GA Twin-Plug

NFlightMic
4400
    Delivery time:3-5 Days
Add to cart
  • Description

The NFlightMic is designed to be a universal microphone allowing pilots to take advantage of high-end noise cancelling headsets available on the consumer electronics market.  While we cater to Bose products because of their quality and dominance in the market, the NFlightMic is compatible with any headset with a 2.5mm audio input jack.  This makes the NFlightMic a truly universal and future-proof solution that is backed by NFlight Technology's unconditional lifetime guarantee.

How it works:  The NFlightMic is an aviation microphone that can be attached to any headset which has a 2.5mm audio input jack using the included 3M Dual Lock.

Attaching the NFlightMic to the Bose QC25

The NFlightMic has a 2.5mm audio output that can be plugged into the headset's auxiliary audio input.

Plugging the NFlightMic into the auxiliary audio input on the Bose QC25

Click here to download the instruction manual in PDF format.

Unconditional Lifetime Warranty:  If you send us a broken NFlightMic, we will replace it up to two times, even if the damage is from abuse.

Compatible with: Bose QC25, Bose QC35, or any other headset with a 2.5mm auxiliary audio input.  Please note: The Bluetooth capability of the Bose QC35 is disabled when the mic is plugged in.

Can also be easily converted to be compatible with headsets with 3.5mm auxiliary audio inputs with the use of a 2.5mm-to-3.5mm adapter.

Popular headsets with a 2.5mm-to-3.5mm adapter:  Bose QC15, Sony 1000

Technical Specifications

General:

Connections - Standard twin-plug PJ-style 3/16-inch and 1/4-inch aviation connectors

Audio output - 2.5mm, 3-pole male connector

Cable length - 2 meters or 39 inches

Audio output cable length - 10 centimeters or 4 inches

Flexible boom microphone length - 20 centimeters or 8 inches

Output volume - adjustable

Attachment to headset - 3M dual lock circles (3M adhesive is removable without a trace.)

Included accessories - shirt clip for strain relief

Microphone:

Noise-canceling electret

Frequency response: 200 Hz - 6000 Hz

Maximum SPL: 114 dB

Terminating impedance: 220-2200 ohms

Operating voltage: 8V-16V DC
